24"W x 20'L Magnapower New Conveyor w/ Magnetic Head Pulley

24"W x 20'L Magnapower New Conveyor w/ Magnetic Head Pulley

Have one to sell?
847-480-8900
director@alanross.biz
Request Financing
Have one to sell?

Document (1)

994.0013 - MC120-600 - Conveyor + Legs + PP22-125FE.pdf

Overview

Type:
Conveyor
Manufacturer:
MAGNAPOWER
Model:
MC60/120
Stock #:
38253
Status:
For Sale

Description

Model MC60/600
Incl. 8.5" Dia x 48" W Magnetic Head Pulley & Splitter

Width48"1,219.2 mm
Length20'6.1 m

Magnetic Head Pulley is 8.5" Dia x 48" W - Model PP22/125
15 ¼“ Sides
Chevron Height: 15 mm
Diameter Feed Roll: 220 mm
Diameter Drive Roll: 220 mm
2.2kW 460Volt 3Phase Electric Motor
Adjustable legs from approximately 11 degrees to about 23 degrees.
C15 belting to accommodate up to a 23 degree angle on many materials without rollback.

All specifications derived from manufacturer's literature and/or representations from third-parties & may be subject to change or contain inaccuracies. Please see ARM Terms & Conditions Of Sale for more information: https://whatboard.app/b/armtandc

Magnetic Head Pulley is 8.5" Dia x 48" W - Model PP22/125
