Harris Wolverine Used Auto Tie Two-Ram Baler

## 📌 Performance Specifications
- **Bale Size:** 46 in. wide x 31 in. high x 61 in. long
- **Bale Volume:** Approximately 50 cubic feet expanded
- **Cycle Time:** 21 seconds (No Load)
- **Capacity:** 7,000 cubic feet per hour (No Load)

## ⚙️ General Specifications
- **Hopper Opening (Top):** 40 3/8 in. x 60 in.
- **Charge Box Opening:** 41 in. x 60 in.
- **Strapper:** L&P Wire-Tie System Model 341 (Standard)
- **Non-Ferrous Liners:** Main frame floor and ram
- **Approximate Shipping Weight:** 23 Tons

## 🏗️ Baling Material Specifications
- **BULK OCC:** Up to 1,250 lbs, 5-8 tons/hr (with Combo Door), 6-9 tons/hr (No Combo Door)
- **Solid Waste:** Up to 1,500 lbs, 9-13 tons/hr
- **Newsprint:** Up to 1,400 lbs, 8-10 tons/hr
- **Whole Aluminum Cans:** Up to 750 lbs, 2-4 tons/hr
- **Steel Cans:** Up to 1,500 lbs, 6-8 tons/hr
- **Plastic:** Up to 900 lbs, up to 4 tons/hr
- **Non-Ferrous:** Up to 1,200 lbs, 4-6 tons/hr
- **High-Density Polyethylene (HDPE):** Up to 1,050 lbs, up to 4 tons/hr

## 🔧 Hydraulic System
- **Main Pumps:** 60 GPM
- **Circulation Pump:** 30 GPM
- **Strapper Pump:** 12 GPM
- **System Pressure:** 3,500 psi
- **Main Ram Force:** 88 tons, 60% ram penetration
- **Main Ram Face Pressure:** Not specified
- **Ejector Ram Face Pressure:** 84 psi
- **Oil Reservoir Capacity:** 160 gallons
- **Oil Cooler & Heater:** Air-to-Oil, Thermostatically Controlled
- **Filtration:** 5-micron

## ⚡ Electrical System
- **Main Motor:** (1) 40HP 460V/3PH/60Hz, 1750 RPM, TEFC
- **Cooling Fan Motor:** 1HP 460V/3PH/60Hz, 1725 RPM, TEFC
- **Starter:** Across-the-line motor starters with overload protection (reduced voltage starting available as an option)
- **Operator Control Console:** UL & CUL listed panels with Operator Interface Terminal (OIT)
- **Conveyor Controls:** (1) 10HP (Standard)
- **Photo Eyes:** Adjustable multi-level material control
- **Enclosures:** NEMA 12 rated (Not for outdoor operation)

## 🏗️ Construction & Design
- **Main Frame & Compression Chamber:** Heavy steel plate with reinforcing ribs, replaceable abrasion-resistant wear surfaces
- **Flooring:** Tongue and groove abrasion-resistant wear plates
- **Knife:** Serrated design
- **Hydraulic Piping:** ASTM A-106 Schedule 160

## 🛠️ Additional Options
- **Reduced Voltage Starting**
- **Conveyors**
- **Climate-Controlled Operator’s Cabin**
- **Bale Runout Table**
- **Hopper Extension**
- **Installation Assistance**
- **Oversized Bale Release Door**
- **Combination Bale Release & Separation Door (Combo Door)**

---

**Note:** Performance rates and/or production rates are subject to material input density, feed rates, and other variables outside the control of the manufacturer.
