ElectroMax Overband Magnet - Equipment Specification Sheet
Overview ✨
The Bunting ElectroMax Overband Magnet offers significantly increased magnetic power and reduced weight compared to traditional permanent overband magnets. It is designed for efficient recovery of ferrous contaminants from various product streams.
Key Features ⚙️
Enhanced Magnetic Power: 185% increase in magnetic power than comparable permanent magnetic equipment.
Reduced Weight: 25% less weight than comparable permanent magnetic equipment.
Air-Cooled Electromagnet: An air-cooled Electromagnet, emitting a high gradient magnetic field enables the ElectroMax to recover small iron contaminants from greater burden depth and also offers a boosted lifting capacity of heavy and odd shaped tramp metals.
Optimized Design: The mild steel core is wound with aluminium foil for maximum heat dissipation, guaranteeing stable maximum magnetic power.
Durable Construction: The magnet system is mounted onto a heavy-duty backplate and enclosed with thick steel side poles to provide optimum magnetic power directed at the product stream.
Impact Protection: An 8mm thick manganese base plate protects the magnet system from impact damage.
Efficient Discharge Belt: Material is efficiently discharged by a wear resistant 3-ply nylon/terylene constructed belt, with fitted vulcanised wiper strips.
Compact & Low Profile: The ElectroMax features the highest magnetic power to weight ratio of any overband magnet due to the design of the air cooled coil which allows the unit to have an overall low profile and compact frame, meaning a downsized dual-pulley system can be used to drive the self-cleaning belt.
Maintenance: Switching off power to the ElectroMax deactivates its magnetic field allowing for easier, convenient maintenance between operations.
Portability: The ideal add on solution for mobile equipment.
